• Combination of synchronous output of multiple test devices, unlimited expansion of output port
• Establish manufacturer equipment data model library and realize automatic configuration of test operation instructions
• Closed-loop automatic test based on multi-channel information output
• Multi-channel equipment model acquisition
• Visual customization of report sheet
• Automatic check of constant value pressing plate

Voltage and current source
Output of AC voltage 12 * (0~300V)
AC current output 18 * (0~30A)
Precision ± 0.05%
output frequency
Range 10~1000Hz
Resolution 0.001Hz
Precision<0.005Hz
Output phase
Range - 360 °~360 °
Resolution<0.1 °
Error<0.1 °
Switching value
Input 15 pairs
Output 20 pairs
Output delay<0.1ms
Clock and synchronization
Time accuracy ≤ 10us (GPS reference synchronization)
Time keeping accuracy ≤ 1ms (8 hours)
Voltage and current synchronization performance ≤ 10us (same device)
Dimension 60cm * 60cm * 110cm
Weight 80kg
